How Do You Choose The Best Plant Trackers?

 ✔ Easy Install  ✔ Wired and wireless options  ✔ Robust up to IP69K standard  ✔ Futureproof technology

Our devices are easy to install; so you save on costs and keep equipment downtime to a minimum. For versatility, the robust, weatherproof unit can be mounted with VHB tape, a bracket, a magnetic jacket or a steel cage. With Lifetime Warranty as standard, you get peace of mind that if the unit develops a fault, our free 24/7 customer support will replace it free of charge.

Get a free demo   Get a price quote

How can you be sure you are choosing the best tracker?

  • Hardware options

    Different plant and equipment have different needs, so choose between a wired device or a small or large wireless device.

  • Easy to Install

    No hidden installation costs, you can even fit yourself at your own convenience and keep equipment downtime to a minimum.

  • Robust hardware

    Reliable, water-resistant, weatherproof and suitable for extreme temperatures (IP69K).

  • Futureproof technology

    Designed, manufactured, tested and updated in-house  so you can be confident that you are getting a solution that evolves with the latest technology.

  • Installation versatility

    Mount the device using VHB tape, a bracket, a magnetic jacket or a steel cage.

  • Lifetime Warranty

    Free hardware replacement as standard on any unit that develops a fault.

  • No map freezes

    We utilise a roaming SIM to connect to the strongest available signal.

  • Transferable Hardware

    Move or remove hardware as you sell or change your equipment.

ABAX Equipment Control

Technical Specifications

 General Specification

Name ABAX5
Dimension 46x46x18mm
Weight <50g
Storage temperature -40C to +75C
Operating temp -20C to +60C
Battery size 39 x 27 x 6.2mm
Battery capacity 500mAh
Supply voltage 7 to 30 VDC
Current usage Active 50mA, Passive 7mA. Sleep <1mA

 Interfaces

Radio communication frequency 433MHz, Bluetooth Smart 4.0, UHF, UHF Beacon
Usage logging or general input Digital or 0-30V analog input voltage (yellow wire)
Storage temperature -40C to +75C
Configuration Automatic OTA (Over The Air update) firmware and configuration updates
Sensors Temperature accelerometer
LED Indicators Power up: Red for 1 minute, and then blink blue for up to 9 minutes. When start up is complete, the LED will stop blinking.
Communication protocol TCP, UDP, SMS
Scheduled report Report position at a preset time interval
Geo-fence Geo-fence alarm


 Environmental Data, Reliability, Certification

Approvals CE
Type Approvals ECE R10.05.2014
IP Grade IP69K
Battery Type Li-on Lipo battery pack

  Location Specification

Location technology GPS, A-GPS, GLONASS, 165dBm sensitivity, 1m accuracy under optimal GPS conditions
Alternative location technology GSM
GSM Module Dual band GSM module - 900 MHz, 1800 MHz GSM/GPS

 General Specification

Name ABAX EQ2S, ABAX EQ2L
Dimension ABAX EQ2S: 86x63x20mm
ABAX EQ2L: 145x63x20mm
Weight ABAX EQ2S: <130g
ABAX EQ2L: <230g
Storage temperature -30C to +30C clean&dry
(less than 30% RH) area
Operating temp -30C to +60C
Battery size ABAX EQ2S: 62x63x20mm
ABAX EQ2L: 121x63x20mm
Battery capacity

ABAX EQ2S: 8Ah
ABAX EQ2L: 16Ah

Battery life*
*this applies to 3 positions per day
ABAX EQ2s: >15 months ABAX EQ2L: >34 months
Supply voltage 3.6 VDC

 Interfaces

Configuration Automatic OTA (Over The Air update) firmware and configuration updates
LED Indicators Active mode indication
Communication Protocol TCP, UDP, SMS
Power Supply Monitoring Alarm status reporting of the internal battery of the device
Scheduled Report Report position at a preset time interval
Geo-fence Geo-fence alarm
Radio communication frequency Bluetooth low energy, UHF, UHF Beacon
Sensors Temperature accelerometer

 Environmental Data, Reliability, Certification

Approvals CE
IP Grade IP67
Battery type Primary Lithium Battery pack

  Location Specification

Location technology GPS, AGPS, GLONASS, 167dBm sensitivity, 1m accuracy under optimal GPS conditions
Alternative location technology GSM
GSM Module Dual band GSM module - 900MHz, 1800MHz GSM/GPS

Live Tracking

Track and Trace EQ

60 sec map refresh rate, Mobile friendly, Google integration, Vehicle, plant and tool tracking.

Benefits of plant tracking

Usage Logging

Usage logging EQ

Predictive Maintenance, Scheduled reports with impact, Servicing alerts, Plant Hire control

Benefits of tracking usage

Theft Protection

Theft Protection EQ

24/7 Support, Anti-tamper protection, Lower insurance premiums, Customised geofences

Protect against theft

Trailer Tracking

Trailer Tracking with EQ

Real-time and historical location, increased trailer utilisation, regulate servicing, time in area reporting

Trailer tracking
